Key Features

Power supply (Normal)

VDD & VDDQ = 1.1V (1.067V (-3%) to 1.166V (+6%));

VPP = 1.8V (1.746V (-3%) to 1.908V (+6%))

VDDSPD = 1.8V

• JEDEC RDIMM Form factor

• Density

32GB (2Rank, x8)

• Data transfer rates:PC5 5600 (CL46)

• ECC Transparency and Error Scrub

• Burst Length (BL): BL16, BC8 OTF, BL32(Optional), BL32 OTF(Optional) are supported

• Bi-directinal Differential Data-Strobe

• 1N/2N Mode is supported for Commands

• Programmable Read/Write preambles and postambles

• On-Die Termination (ODT) via Mode Register setting: RTT_PARK, RTT_WR, RTT_NOM_WR, RTT_NOM_RD, DQS_RTT_PARK

• Same Bank Refresh and All Bank Refresh for Normal Refresh Mode and Fine Granularity Refresh Mode

• Array Configuration : 32banks(8 bank groups, 4 banks for each bank group) for x4/x8;

• Per DRAM Addressability (PDA)/ Maximum Power Saving Mode (MPSM)/ Multi-Purpose Command (MPC)

• Tc of 0°C to 95°C

3.9 μs/32ms, 8K cycles at 0°C ≤ TCase ≤ 85°C / 1.95 μs/16ms, 8K cycles at 85°C < TCase ≤ 95°C

• Lead- free and Halogen-free products are RoHS Compliant
