INT210Y High-Performance MEMS 3-Axis Gyroscope
INT210Y is a 3-axis high-performance MEMS gyroscope that meets the requirements of aerospace application. It has been used in dozens of commercial satellites, with in-orbit application time over three years. Every gyroscope will do full temperature calibration during manufacture process.And,it has passed tests such as thermal vacuum, EMC, magnetic testing, and total dose irradiation test.
Specifications
|
PRODUCT MODEL |
Units |
INT210Y |
|
MEMS Gyroscope |
||
|
Range |
°/s |
±100/±100/±100 |
|
Bias |
°/h |
10/10/5 |
|
Bias Instability |
°/h |
0.5/0.1/0.03 |
|
Bias Stability Over Temperature (10s 1σ) |
°/h |
5/1/0.3 |
|
Bias Repeatability(1σ) |
°/h |
5/1/0.3 |
|
Angle Random Walk |
/ √ h |
0.15/0.05/0.01 |
|
Scale Factor Nonlinearity |
ppm |
200/100/100 |
|
Scale Factor Repeatability |
ppm |
200/100/100 |
|
Orthogonality |
% |
0.1 |
|
Bandwidth |
Hz |
10 |
|
System Specifications |
||
|
Power Supply Voltage |
V |
5±0.5 |
|
Power Consumption |
W |
1.5 |
|
Dimensions(L x W x H) |
mm |
44.8×38.6×21.5 |
|
Weight |
g |
48±5 |
|
Operating Temperature |
℃ |
-40~+85 |
|
start-up time |
S |
1 |
|
Output Frequency |
Hz |
Supports Blind Sending Supports Polled Mode Output |
|
Interface |
||
|
Electrical Interface |
|
RS422×1 |
|
Connector |
|
J30J-15ZK |
Application
- Commercial aerospace
- Commercial sat
- Cargo spaceship
- ＜800km LEO
