Product Applications
This product is primarily used in high-reliability and high-speed signal read/write control applications.
Main Features
- Capacity: 144 Mbit, 4M × 36 bit
- Part Number: ZDSD4M36-PGAD
- Maximum Operating Frequency: 333 MHz
- Operating Voltage: 1.8V (Core), 1.5V/1.8V (IO)
- Operating Mode: Synchronous
- Operating Temperature: -55℃ ~ 125℃
- Storage Temperature: -65℃ ~ 150℃
- Package Type: FBGA 165
- ESD Rating: 2000V (HBM)
Feature Description
- Double Data Rate (DDR) interface at 333 MHz frequency (data transfer rate of 666 MHz)
- Synchronous internal self-timed write
- When #DOFF is high, DDR II access latency is 1.5 cycles; when #DOFF is low, it operates in a DDR I-like mode with a 1-cycle access latency
- 1.8V core voltage, supports HSTL high-speed transceiver protocol
- Extended HSTL output voltage (supports 1.5V and 1.8V IO voltage)
- JTAG 1149.1 compatible test access port
- Built-in Delay-Locked Loop (DLL)
